Technical details
Vendor	APC by Schneider Electric
Ports & interfaces
Number of type F outputs	8
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	3
USB port	Y
AC outlets quantity	8 AC outlet(s)
Power plug	Type F
AC outlet types	Type F
Weight & dimensions
Height	120 mm
Width	130 mm
Depth	365 mm
Weight	4500 g
Battery
Battery recharge time	16 h
Typical backup time at half load	9 min
Typical backup time at full load	2 min
Battery life (max)	5 year(s)
Hot-swap battery	Y
Battery technology	Sealed Lead Acid (VRLA)
Battery capacity	93 Ah
Cold start	Y
Automatic battery test	Y
Design
Cable length	1.83 m
LED indicators	Y
Product colour	Black
Certification	REACH, CE, EAC
RoHS compliance	Y
Form factor	Compact
Features
Waveform	Sine
Automatic Voltage Regulation (AVR)	Y
Audible alarm(s)	Y
UPS topology	Standby (Offline)
Output power capacity	800 VA
Surge energy rating	310 J
Noise level	45 dB
Audible alarm modes	Alarm when on battery,Low battery alarm,Overload alarm
Input frequency	47/63 Hz
Maximum current	6 A
Output power	520 W
Surge protection	Y
Surge protection features	Digital Subscriber Line (DSL),Fax,Modem,Network,Telephone
Input operation voltage (max)	230 V
Input operation voltage (min)	220 V
Output operation voltage (min)	220 V
Output operation voltage (max)	230 V
Output frequency	47/63 Hz
Logistics data
Master (outer) case gross weight	16000 g
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Non-operating altitude	0 - 4500 m
Operating altitude	0 - 900 m
Operating relative humidity (H-H)	0 - 90 %
Storage temperature (T-T)	-15 - 45 °C
Packaging data
Package depth	441 mm
Package height	190 mm
Package width	186 mm
Manual	Y
Package weight	5000 g
