Specifikacije proizvoda

Technical details
Vendor	LC-Power
Sustainability compliance	Yes
Sustainability certificates	CE, TUV
Warranty period	3 year(s)
Packaging content
Cables included	PATA, PCIe, SATA
Ports & interfaces
Motherboard power cable length	650 mm
SATA power cable length	500.650.800.950 mm
Peripheral (Molex) power cable length	500.800 mm
EPS power connector (4+4 pin)	Yes
PCI Express power connectors (12+4 pin)	2
Motherboard power connector	20+4 pin ATX
Number of SATA power connectors	20
Peripheral (Molex) power connectors (4-pin)	2
EPS power connector (8-pin)	Yes
ATX power connector (20+4 pin)	Yes
PCI Express power connectors (6+2 pin)	6
Cabling type	Modular
Number of PATA power connectors	6
Weight & dimensions
Height	150 mm
Width	86 mm
Depth	180 mm
Weight	3670 g
Design
Product colour	Black
Number of fans	1 fan(s)
On (off switch)	Yes
Cooling type	Active
Fan diameter	135 mm
Performance
Power supply unit (PSU) form factor	ATX
Supported motherboard form factors	ATX
ATX version	3.0
80 PLUS certification	80 PLUS Platinum
Power
Total power	1200 W
Efficiency	92 %
Power protection features	Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Power Factor Correction (PFC) type	Active
Combined power (+3.3V)	100 W
Combined power (+12V)	1200 W
Combined power (+5V)	100 W
Combined power (-12V)	3.6 W
Combined power (+5Vsb)	15 W
Max output current (+3.3V)	20 A
Max output current (+12V)	100 A
Max output current (+5V)	20 A
Max output current (-12V)	0.3 A
Max output current (+5Vsb)	3 A
AC input frequency	47 - 60 Hz
AC input voltage	110 - 240 V
Packaging data
Package depth	295 mm
Package height	225 mm
Package width	120 mm
Package type	Box
Package weight	4030 g
