| CPU | LGA1851 socket: Support for Intel® Core™ Ultra Processors L3 cache varies with CPU * Please refer to "CPU Support List" for more information |
| Chipset | Intel® Z890 Express Chipset |
| Memory | Support for DDR5 9500(O.C) / 9466(O.C) / 9333(O.C) / 9200(O.C)/9066(O.C)/8933(O.C)/8800(O.C)/8600(O.C)/8400(O.C)/8266(O.C)/8200(O.C)/8000(O.C)/7950(O.C)/7900(O.C)/7800(O.C)/7600(O.C.)/7400(O.C.)/7200(O.C.)/7000(O.C.)/6800(O.C.)/6600(O.C.)/6400/6200/6000/5800/5600 MT/s memory modules 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules Support CUDIMM memory module *(Refer to "Memory Support List" for more information) |
| Onboard Graphics | Integrated Graphics Processor-Intel® HD Graphics support: - 2 x Intel® Thunderbolt™ 4 connectors (USB4® USB Type-C® ports), supporting DisplayPort and Thunderbolt™ video outputs - Max resolution for Thunderbolt monitor: 5120x2880@60 Hz (single display) - Max resolution for USB4® Type-C® monitor: 3840x2160@240 Hz (single display) - 1 x front HDMI port, max resolution 1920x1080@30 Hz * Support for DisplayPort 1.4 and HDMI 1.4 versions, HDCP 2.3 Support for up to triple-display at the same time |
| Audio | Realtek® ALC1220 CODEC High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out * Back panel line out jack supports DSD audio |
| LAN | Realtek® 5GbE LAN chip (5 Gbps/2.5 Gbps/1 Gbps/100 Mbps) |
| Wireless | Intel® Wi-Fi 7 BE200: 802.11a/b/g/n/ac/ax/be (2.4/5/6 GHz) BLUETOOTH 5.4 Support for 11be 320MHz wireless standard * Wi-Fi 7 features require Windows 11 SV3 |
| Expansion Slots | CPU: 1 x PCI Express x16 slot (PCIe 5.0, x16) Chipset: 1 x PCI Express x16 slot (PCIe 4.0, x4), 1 x PCI Express x16 slot (PCIe 4.0, x1) |
| Storage Interface | CPU: - 1 x M.2 (25110/22110/2580/2280 PCIe 5.0 x4/x2) (M2A_CPU) - 1 x M.2 (22110/2280 PCIe 4.0 x4/x2) (M2B_CPU) Chipset: - 1 x M.2 (22110/2280 PCIe 4.0 x4/x2) (M2Q_SB) - 1 x M.2 (2280 PCIe 4.0 x4/x2) (M2P_SB) - 1 x M.2 (2280 SATA/PCIe 4.0 x4/x2) (M2M_SB) - 4 x SATA 6Gb/s connectors RAID 0/1/5/10 support for NVMe and SATA storage devices |
| USB | CPU: 2 x Intel® Thunderbolt™ 4 (USB Type-C®) ports (40Gbps TB, 20Gbps USB4, 10Gbps USB 3.2) Chipset: - 1 x USB Type-C® (USB 3.2 Gen 2x2, internal) - 2 x USB 3.2 Gen 2 Type-A (rear, red) - 6 x USB 3.2 Gen 1 (4 rear, 2 internal) - 8 x USB 2.0/1.1 (4 rear, 4 internal) |
| Internal I/O Connectors | 1 x 24-pin ATX main power 2 x 8-pin ATX 12V power 1 x CPU fan header 1 x CPU fan/water cooling pump header 4 x system fan headers 2 x system fan/water cooling pump headers 3 x addressable RGB Gen2 LED headers 1 x RGB LED header 5 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x HDMI port 1 x USB Type-C® header (USB 3.2 Gen 2x2) 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 1 x TPM header 1 x Q-Flash Plus button 1 x noise detection header 1 x power button 1 x reset button 1 x reset jumper 1 x Clear CMOS jumper 2 x temperature sensor headers |
| Back Panel Connectors | 4 x USB 2.0/1.1 2 x antenna connectors (2T2R) 4 x USB 3.2 Gen 1 2 x Intel® Thunderbolt™ 4 (USB Type-C®) 2 x USB 3.2 Gen 2 Type-A (red) 1 x RJ-45 port 1 x optical S/PDIF Out 2 x audio jacks |
| I/O Controller | iTE® I/O Controller Chip |
| H/W Monitoring | Voltage, Temperature, Fan speed, Water cooling flow rate, Fan fail warning, Fan speed control, Noise detection |
| BIOS | 1 x 256 Mbit flash, AMI UEFI BIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Unique Features | GIGABYTE Control Center (GCC), Q-Flash, Q-Flash Plus, Smart Backup |
| Bundled Software | Norton® Internet Security (OEM), LAN bandwidth management software |
| Operating System | Support for Windows 11 64-bit |
| Form Factor | ATX Form Factor; 30.5cm x 24.4cm |
Pređite na informacije o proizvodu
Opis
| CPU | LGA1851 socket: Support for Intel® Core™ Ultra Processors L3 cache varies with CPU * Please refer to "CPU Support List" for more information |
| Chipset | Intel® Z890 Express Chipset |
| Memory | Support for DDR5 9500(O.C) / 9466(O.C) / 9333(O.C) / 9200(O.C)/9066(O.C)/8933(O.C)/8800(O.C)/8600(O.C)/8400(O.C)/8266(O.C)/8200(O.C)/8000(O.C)/7950(O.C)/7900(O.C)/7800(O.C)/7600(O.C.)/7400(O.C.)/7200(O.C.)/7000(O.C.)/6800(O.C.)/6600(O.C.)/6400/6200/6000/5800/5600 MT/s memory modules 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules Support CUDIMM memory module *(Refer to "Memory Support List" for more information) |
| Onboard Graphics | Integrated Graphics Processor-Intel® HD Graphics support: - 2 x Intel® Thunderbolt™ 4 connectors (USB4® USB Type-C® ports), supporting DisplayPort and Thunderbolt™ video outputs - Max resolution for Thunderbolt monitor: 5120x2880@60 Hz (single display) - Max resolution for USB4® Type-C® monitor: 3840x2160@240 Hz (single display) - 1 x front HDMI port, max resolution 1920x1080@30 Hz * Support for DisplayPort 1.4 and HDMI 1.4 versions, HDCP 2.3 Support for up to triple-display at the same time |
| Audio | Realtek® ALC1220 CODEC High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out * Back panel line out jack supports DSD audio |
| LAN | Realtek® 5GbE LAN chip (5 Gbps/2.5 Gbps/1 Gbps/100 Mbps) |
| Wireless | Intel® Wi-Fi 7 BE200: 802.11a/b/g/n/ac/ax/be (2.4/5/6 GHz) BLUETOOTH 5.4 Support for 11be 320MHz wireless standard * Wi-Fi 7 features require Windows 11 SV3 |
| Expansion Slots | CPU: 1 x PCI Express x16 slot (PCIe 5.0, x16) Chipset: 1 x PCI Express x16 slot (PCIe 4.0, x4), 1 x PCI Express x16 slot (PCIe 4.0, x1) |
| Storage Interface | CPU: - 1 x M.2 (25110/22110/2580/2280 PCIe 5.0 x4/x2) (M2A_CPU) - 1 x M.2 (22110/2280 PCIe 4.0 x4/x2) (M2B_CPU) Chipset: - 1 x M.2 (22110/2280 PCIe 4.0 x4/x2) (M2Q_SB) - 1 x M.2 (2280 PCIe 4.0 x4/x2) (M2P_SB) - 1 x M.2 (2280 SATA/PCIe 4.0 x4/x2) (M2M_SB) - 4 x SATA 6Gb/s connectors RAID 0/1/5/10 support for NVMe and SATA storage devices |
| USB | CPU: 2 x Intel® Thunderbolt™ 4 (USB Type-C®) ports (40Gbps TB, 20Gbps USB4, 10Gbps USB 3.2) Chipset: - 1 x USB Type-C® (USB 3.2 Gen 2x2, internal) - 2 x USB 3.2 Gen 2 Type-A (rear, red) - 6 x USB 3.2 Gen 1 (4 rear, 2 internal) - 8 x USB 2.0/1.1 (4 rear, 4 internal) |
| Internal I/O Connectors | 1 x 24-pin ATX main power 2 x 8-pin ATX 12V power 1 x CPU fan header 1 x CPU fan/water cooling pump header 4 x system fan headers 2 x system fan/water cooling pump headers 3 x addressable RGB Gen2 LED headers 1 x RGB LED header 5 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x HDMI port 1 x USB Type-C® header (USB 3.2 Gen 2x2) 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 1 x TPM header 1 x Q-Flash Plus button 1 x noise detection header 1 x power button 1 x reset button 1 x reset jumper 1 x Clear CMOS jumper 2 x temperature sensor headers |
| Back Panel Connectors | 4 x USB 2.0/1.1 2 x antenna connectors (2T2R) 4 x USB 3.2 Gen 1 2 x Intel® Thunderbolt™ 4 (USB Type-C®) 2 x USB 3.2 Gen 2 Type-A (red) 1 x RJ-45 port 1 x optical S/PDIF Out 2 x audio jacks |
| I/O Controller | iTE® I/O Controller Chip |
| H/W Monitoring | Voltage, Temperature, Fan speed, Water cooling flow rate, Fan fail warning, Fan speed control, Noise detection |
| BIOS | 1 x 256 Mbit flash, AMI UEFI BIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Unique Features | GIGABYTE Control Center (GCC), Q-Flash, Q-Flash Plus, Smart Backup |
| Bundled Software | Norton® Internet Security (OEM), LAN bandwidth management software |
| Operating System | Support for Windows 11 64-bit |
| Form Factor | ATX Form Factor; 30.5cm x 24.4cm |
Trenutno nema sadržaja u ovom odeljku.
Gigabyte Z890 AORUS PRO ICE
Regularna cena
43,100.00 RSD
