Processor | |
Processor manufacturer | AMD |
Maximum number of SMP processors | 1 |
Compatible processor series | AMD Ryzen 3 3rd Gen, 3rd Generation AMD Ryzen 5, 3rd Generation AMD Ryzen 7, 3rd Generation AMD Ryzen 9 |
Processor socket | Socket AM4 |
Memory | |
Memory slots type | DIMM |
Maximum internal memory | 128 GB |
Number of memory slots | 4 |
Supported memory clock speeds | 2133.2400.2666.2800.3000.3200.3466.3600.3866.4000.4133.4400.4600 MHz |
Supported memory types | DDR4-SDRAM |
Network | |
Ethernet LAN | Y |
Bluetooth | 5.0 Y |
Wake-on-LAN ready | Y |
LAN controller | Intel I225-V |
Wi-Fi | N |
Ethernet interface | 2.5 Gigabit Ethernet |
Technical details | |
Vendor | Asustek |
Packaging content | |
Cables included | SATA |
Manual | Y |
Drivers included | Y |
Expansion slots | |
PCI Express x1 (Gen 3.x) slots | 3 |
PCI Express x16 (Gen 3.x) slots | 1 |
Number of M.2 (M) slots | 2 |
PCI Express x16 (Gen 4.x) slots | 1 |
PCI Express slots version | 3.0,4.0 |
BIOS | |
BIOS memory size | 256000 Mbit |
BIOS type | UEFI AMI |
Weight & dimensions | |
Width | 305 mm |
Depth | 244 mm |
Graphics | |
Parallel processing technology support | 2-Way CrossFireX |
Features | |
Motherboard form factor | ATX |
Audio output channels | 7.1 channels |
Motherboard chipset | AMD B550 |
Cooling type | Active |
PC health monitoring | CPU, Fan |
Windows operating systems supported | Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 IoT Enterprise,Windows 10 Pro,Windows 10 Pro x64,Windows 10 x64 |
Power source type | ATX |
Motherboard chipset family | AMD |
Component for | PC |
Internal I/O | |
Thunderbolt headers | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
12V power connector | Y |
USB 2.0 connectors | 2 |
CPU fan connector | Y |
Number of EATX power connectors | 1 |
Number of chassis fan connectors | 3 |
EPS power connector (8-pin) | Y |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
Number of SATA III connectors | 6 |
Rear panel I/O ports | |
DisplayPort version | 1.2 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
USB 2.0 ports quantity | 2 |
Ethernet LAN (RJ-45) ports | 1 |
Headphone outputs | 1 |
Microphone in | Y |
S (B 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - B 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity - B 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity - B 2.0 ports quantity - PDIF out port) | 4 - 1 - 1 - 2 - Y |
HDMI ports quantity | 1 |
HDMI version | 2.1 |
DisplayPorts quantity | 1 |
Storage controllers | |
RAID levels | 0,1,10 |
Supported storage drive types | HDD & SSD |
Storage interfaces | M.2,SATA III |
Number of HDDs supported | 6 |
Pređite na informacije o proizvodu
Opis
ASUS ROG STRIX B550-F GAMING AM4 B550/M.2/ATX PCI-Express 4.0 Support
Regularna cena
22,600.00 RSD
Ostvarite popust od 3% kada plaćate gotovinom u našoj prodavnici.
Kontaktirajte Nas
Šifra proizvoda:
2110204
Adding product to your cart
Processor | |
Processor manufacturer | AMD |
Maximum number of SMP processors | 1 |
Compatible processor series | AMD Ryzen 3 3rd Gen, 3rd Generation AMD Ryzen 5, 3rd Generation AMD Ryzen 7, 3rd Generation AMD Ryzen 9 |
Processor socket | Socket AM4 |
Memory | |
Memory slots type | DIMM |
Maximum internal memory | 128 GB |
Number of memory slots | 4 |
Supported memory clock speeds | 2133.2400.2666.2800.3000.3200.3466.3600.3866.4000.4133.4400.4600 MHz |
Supported memory types | DDR4-SDRAM |
Network | |
Ethernet LAN | Y |
Bluetooth | 5.0 Y |
Wake-on-LAN ready | Y |
LAN controller | Intel I225-V |
Wi-Fi | N |
Ethernet interface | 2.5 Gigabit Ethernet |
Technical details | |
Vendor | Asustek |
Packaging content | |
Cables included | SATA |
Manual | Y |
Drivers included | Y |
Expansion slots | |
PCI Express x1 (Gen 3.x) slots | 3 |
PCI Express x16 (Gen 3.x) slots | 1 |
Number of M.2 (M) slots | 2 |
PCI Express x16 (Gen 4.x) slots | 1 |
PCI Express slots version | 3.0,4.0 |
BIOS | |
BIOS memory size | 256000 Mbit |
BIOS type | UEFI AMI |
Weight & dimensions | |
Width | 305 mm |
Depth | 244 mm |
Graphics | |
Parallel processing technology support | 2-Way CrossFireX |
Features | |
Motherboard form factor | ATX |
Audio output channels | 7.1 channels |
Motherboard chipset | AMD B550 |
Cooling type | Active |
PC health monitoring | CPU, Fan |
Windows operating systems supported | Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 IoT Enterprise,Windows 10 Pro,Windows 10 Pro x64,Windows 10 x64 |
Power source type | ATX |
Motherboard chipset family | AMD |
Component for | PC |
Internal I/O | |
Thunderbolt headers | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
12V power connector | Y |
USB 2.0 connectors | 2 |
CPU fan connector | Y |
Number of EATX power connectors | 1 |
Number of chassis fan connectors | 3 |
EPS power connector (8-pin) | Y |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
Number of SATA III connectors | 6 |
Rear panel I/O ports | |
DisplayPort version | 1.2 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
USB 2.0 ports quantity | 2 |
Ethernet LAN (RJ-45) ports | 1 |
Headphone outputs | 1 |
Microphone in | Y |
S (B 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - B 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity - B 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity - B 2.0 ports quantity - PDIF out port) | 4 - 1 - 1 - 2 - Y |
HDMI ports quantity | 1 |
HDMI version | 2.1 |
DisplayPorts quantity | 1 |
Storage controllers | |
RAID levels | 0,1,10 |
Supported storage drive types | HDD & SSD |
Storage interfaces | M.2,SATA III |
Number of HDDs supported | 6 |
Trenutno nema sadržaja u ovom odeljku.
ASUS ROG STRIX B550-F GAMING AM4 B550/M.2/ATX PCI-Express 4.0 Support
Regularna cena
22,600.00 RSD
