Product specifications

Technical details
Vendor	Online USV-Systeme AG
Output connections	IEC320 C13
Input connections	IEC320 C20
Charging time	4 h
Output frequency	50/60 Hz
Packaging content
Cables included	Input power cable, Power load cable, USB cable
Ports & interfaces
Serial interface type	RS-232
Serial ports quantity	1
Serial interface	Y
USB 2.0 ports quantity	1
USB port	Y
AC outlets quantity	8 AC outlet(s)
RS-232 ports	1
Power plug	C20 coupler
AC outlet types	C13 coupler
Weight & dimensions
Height	88 mm
Width	438 mm
Depth	512 mm
Weight	19500 g
Battery
Number of batteries supported	4
Battery recharge time	4 h
Typical backup time at half load	16 min
Typical backup time at full load	6 min
Battery voltage	12 V
Battery capacity	9 Ah
Cold start	Y
Design
Product colour	Black
Rack capacity	2U
Mean time between failures (MTBF)	50000 h
Form factor	Rackmount/Tower
International Protection (IP) code	IP20
Display	LCD
Performance
Waveform	Sine
Audible alarm(s)	Y
UPS topology	Double-conversion (Online)
Noise level	50 dB
Audible alarm modes	Low battery alarm, Overload alarm
Cooling type	Active
Surge protection features	Fax, Modem, Network
Features
Package type	Box
Power
Power supply input frequency	50/60 Hz
Emergency Power Off (EPO)	Y
Output power capacity	2000 VA
Maximum current	15.3 A
Efficiency	97 %
Output power	2000 W
Input operation voltage (max)	300 V
Input operation voltage (min)	110 V
Output operation voltage (min)	208 V
Output operation voltage (max)	240 V
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 90 %
Certificates
Certification	VFI-SS-111 (EN62040-3)\nEN62040-1\nEN62040-2\nCE
Management features
Management protocols	SNMP
