| Processor | |
| Built-in processor | N |
| Network | |
| Ethernet LAN | Y |
| LAN controller | Intel® I211 |
| Wi-Fi | N |
| Design | |
| Chassis type | 1L sized PC |
| Kensington Lock | Y |
| Product type | Mini PC barebone |
| Cable lock slot type | Kensington |
| LED indicators | HDD,Power |
| VESA mounting | Y |
| Product colour | Black |
| Certification | FCC, CE, BSMI, RCM, VCCI, RoHS, ErP |
| VESA mounting interface | 75 x 75.100 x 100 mm |
| Housing material | Metal |
| Safety | ETL, CB, BSMI |
| On (off switch) | Y |
| Cooling type | Active |
| Energy Star certified | Y |
| Storage | |
| Supported storage drive types | HDD,SSD |
| SSD form factor | 2.5" |
| Card reader integrated | Y |
| Compatible memory cards | SD |
| Storage drive interface | Serial ATA III |
| Number of storage drives supported | 1 |
| Storage drive sizes supported | 2.5 " |
| Technical details | |
| Vendor | Shuttle |
| Packaging content | |
| AC adapter included | Y |
| Display included | N |
| Mouse included | N |
| Keyboard included | N |
| Quick start guide | Y |
| Power cord included | Y |
| Drivers included | Y |
| Ports & interfaces | |
| DisplayPort version | 1.2 |
| Serial ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 2.0 ports quantity | 4 |
| Ethernet LAN (RJ-45) ports | 2 |
| Headphone outputs | 1 |
| Microphone in | Y |
| DC-in jack | Y |
| COM ports quantity | 2 |
| HDMI ports quantity | 1 |
| HDMI version | 2.0 |
| DisplayPorts quantity | 1 |
| Number of SATA III connectors | 1 |
| Expansion slots | |
| Number of M.2 (M) slots | 2 |
| Weight & dimensions | |
| Height | 43 mm |
| Width | 190 mm |
| Depth | 165 mm |
| Package weight | 2100 g |
| Weight | 1300 g |
| Graphics | |
| Number of displays supported | 2 |
| Maximum resolution | 3840 x 2160 pixels |
| Graphics card family | Intel |
| On-board graphics card | Y |
| Performance | |
| Compatible processor series | Intel® Celeron®, Intel® Core™ i3, Intel Core i5, Intel Core i7, Intel® Pentium® |
| BIOS type | UEFI AMI |
| Audio output channels | 5.1 channels |
| Processor socket | LGA 1151 (Socket H4) |
| Harmonized System (HS) code | 84733080 |
| Audio chip | Realtek ALC662 |
| Operating system | N |
| Motherboard chipset | Intel® H310 |
| Number of processors supported | 1 |
| Windows operating systems supported | Windows 10 |
| Linux operating systems supported | Y |
| Power | |
| Power supply | 90 W |
| Power supply type | External AC adapter |
| Number of power supply units | 1 |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| AC adapter output voltage | 19 V |
| AC adapter output current | 4.74 A |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
| Memory | |
| Memory slots type | SO-DIMM |
| Maximum internal memory | 32 GB |
| Number of memory slots | 2 |
| Non-ECC | Y |
| Memory voltage | 1.2 V |
| Supported memory clock speeds | 2400.2666 MHz |
| Supported memory types | DDR4-SDRAM |
| Memory channels | Dual |
| Audio | |
| Built-in speaker(s) | N |
Pređite na informacije o proizvodu
Opis
| Processor | |
| Built-in processor | N |
| Network | |
| Ethernet LAN | Y |
| LAN controller | Intel® I211 |
| Wi-Fi | N |
| Design | |
| Chassis type | 1L sized PC |
| Kensington Lock | Y |
| Product type | Mini PC barebone |
| Cable lock slot type | Kensington |
| LED indicators | HDD,Power |
| VESA mounting | Y |
| Product colour | Black |
| Certification | FCC, CE, BSMI, RCM, VCCI, RoHS, ErP |
| VESA mounting interface | 75 x 75.100 x 100 mm |
| Housing material | Metal |
| Safety | ETL, CB, BSMI |
| On (off switch) | Y |
| Cooling type | Active |
| Energy Star certified | Y |
| Storage | |
| Supported storage drive types | HDD,SSD |
| SSD form factor | 2.5" |
| Card reader integrated | Y |
| Compatible memory cards | SD |
| Storage drive interface | Serial ATA III |
| Number of storage drives supported | 1 |
| Storage drive sizes supported | 2.5 " |
| Technical details | |
| Vendor | Shuttle |
| Packaging content | |
| AC adapter included | Y |
| Display included | N |
| Mouse included | N |
| Keyboard included | N |
| Quick start guide | Y |
| Power cord included | Y |
| Drivers included | Y |
| Ports & interfaces | |
| DisplayPort version | 1.2 |
| Serial ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 2.0 ports quantity | 4 |
| Ethernet LAN (RJ-45) ports | 2 |
| Headphone outputs | 1 |
| Microphone in | Y |
| DC-in jack | Y |
| COM ports quantity | 2 |
| HDMI ports quantity | 1 |
| HDMI version | 2.0 |
| DisplayPorts quantity | 1 |
| Number of SATA III connectors | 1 |
| Expansion slots | |
| Number of M.2 (M) slots | 2 |
| Weight & dimensions | |
| Height | 43 mm |
| Width | 190 mm |
| Depth | 165 mm |
| Package weight | 2100 g |
| Weight | 1300 g |
| Graphics | |
| Number of displays supported | 2 |
| Maximum resolution | 3840 x 2160 pixels |
| Graphics card family | Intel |
| On-board graphics card | Y |
| Performance | |
| Compatible processor series | Intel® Celeron®, Intel® Core™ i3, Intel Core i5, Intel Core i7, Intel® Pentium® |
| BIOS type | UEFI AMI |
| Audio output channels | 5.1 channels |
| Processor socket | LGA 1151 (Socket H4) |
| Harmonized System (HS) code | 84733080 |
| Audio chip | Realtek ALC662 |
| Operating system | N |
| Motherboard chipset | Intel® H310 |
| Number of processors supported | 1 |
| Windows operating systems supported | Windows 10 |
| Linux operating systems supported | Y |
| Power | |
| Power supply | 90 W |
| Power supply type | External AC adapter |
| Number of power supply units | 1 |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| AC adapter output voltage | 19 V |
| AC adapter output current | 4.74 A |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
| Memory | |
| Memory slots type | SO-DIMM |
| Maximum internal memory | 32 GB |
| Number of memory slots | 2 |
| Non-ECC | Y |
| Memory voltage | 1.2 V |
| Supported memory clock speeds | 2400.2666 MHz |
| Supported memory types | DDR4-SDRAM |
| Memory channels | Dual |
| Audio | |
| Built-in speaker(s) | N |
Trenutno nema sadržaja u ovom odeljku.
Shuttle Barebone XPC slim DH610 Black
Regularna cena
38,200.00 RSD
