| Technical details | |
| Vendor | Online USV-Systeme AG |
| Packaging content | |
| Rack mount kit | Y |
| Cables included | Power load cable, USB cable |
| Quick installation guide | Y |
| Ports & interfaces | |
| Serial interface type | RS-232 |
| Serial interface | Y |
| USB 2.0 ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| USB port | Y |
| AC outlets quantity | 8 AC outlet(s) |
| RS-232 ports | 1 |
| Power plug | C14 coupler |
| AC outlet types | C13 coupler |
| Weight & dimensions | |
| Height | 88 mm |
| Width | 438 mm |
| Depth | 412 mm |
| Weight | 14500 g |
| Battery | |
| Typical backup time at half load | 19 min |
| Typical backup time at full load | 7 min |
| Hot-swap battery | Y |
| Battery voltage | 24 V |
| Battery capacity | 12 Ah |
| Cold start | Y |
| Design | |
| Product colour | Black |
| Rack capacity | 2U |
| Mean time between failures (MTBF) | 50000 h |
| Form factor | Rackmount/Tower |
| International Protection (IP) code | IP20 |
| Display | LCD |
| Performance | |
| UPS topology | Line-Interactive |
| Noise level | 45 dB |
| Power | |
| Output voltage regulation | +3 - -3 % |
| Output frequency regulation | 50/60 Hz |
| Power supply input frequency | 50/60 Hz |
| Output power capacity | 1000 VA |
| Maximum current | 7.4 A |
| Efficiency | 97 % |
| Output power | 900 W |
| Input operation voltage (max) | 274 V |
| Input operation voltage (min) | 176 V |
| Output operation voltage (min) | 208 V |
| Output operation voltage (max) | 240 V |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 0 - 90 % |
| Certificates | |
| Certification | EN62040-2 (EN61000-2-2, EN61000-3-2, EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-8), CE |
| Safety | EN62040-1 |
Skip to product information
Description
| Technical details | |
| Vendor | Online USV-Systeme AG |
| Packaging content | |
| Rack mount kit | Y |
| Cables included | Power load cable, USB cable |
| Quick installation guide | Y |
| Ports & interfaces | |
| Serial interface type | RS-232 |
| Serial interface | Y |
| USB 2.0 ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| USB port | Y |
| AC outlets quantity | 8 AC outlet(s) |
| RS-232 ports | 1 |
| Power plug | C14 coupler |
| AC outlet types | C13 coupler |
| Weight & dimensions | |
| Height | 88 mm |
| Width | 438 mm |
| Depth | 412 mm |
| Weight | 14500 g |
| Battery | |
| Typical backup time at half load | 19 min |
| Typical backup time at full load | 7 min |
| Hot-swap battery | Y |
| Battery voltage | 24 V |
| Battery capacity | 12 Ah |
| Cold start | Y |
| Design | |
| Product colour | Black |
| Rack capacity | 2U |
| Mean time between failures (MTBF) | 50000 h |
| Form factor | Rackmount/Tower |
| International Protection (IP) code | IP20 |
| Display | LCD |
| Performance | |
| UPS topology | Line-Interactive |
| Noise level | 45 dB |
| Power | |
| Output voltage regulation | +3 - -3 % |
| Output frequency regulation | 50/60 Hz |
| Power supply input frequency | 50/60 Hz |
| Output power capacity | 1000 VA |
| Maximum current | 7.4 A |
| Efficiency | 97 % |
| Output power | 900 W |
| Input operation voltage (max) | 274 V |
| Input operation voltage (min) | 176 V |
| Output operation voltage (min) | 208 V |
| Output operation voltage (max) | 240 V |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 0 - 90 % |
| Certificates | |
| Certification | EN62040-2 (EN61000-2-2, EN61000-3-2, EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-8), CE |
| Safety | EN62040-1 |
There is currently no content in this section. Use the sidebar to add material to this section.
ONLINE USV Zinto 1000 VA
Regular price
49,200.00 RSD
