| Technical details | |
| Vendor | be quiet |
| Sustainability certificates | RoHS, ENERGY STAR |
| Warranty period | 5 year(s) |
| Ports & interfaces | |
| Motherboard power cable length | 550 mm |
| SATA power cable length | 500 mm |
| CPU power cable length | 600 mm |
| Peripheral (Molex) power cable length | 790 mm |
| PCI Express power cable length | 500 mm |
| Motherboard power connector | 20+4 pin ATX |
| Number of SATA power connectors | 6 |
| Peripheral (Molex) power connectors (4-pin) | 1 |
| ATX power connector (20+4 pin) | Y |
| CPU power connector (4+4 pin) | Y |
| CPU P4 connector (4-pin) | 1 |
| PCI Express power connectors (6+2 pin) | 2 |
| Cabling type | Non-Modular |
| Number of PATA power connectors | 2 |
| Weight & dimensions | |
| Height | 86 mm |
| Width | 150 mm |
| Depth | 140 mm |
| Weight | 1980 g |
| Other features | |
| Screws included | Y |
| Noise level (quiet mode, 50%) | 12.8 dB |
| Noise level (full-load mode, 100%) | 31.2 dB |
| Noise level (silent mode, <30%) | 9.2 dB |
| Design | |
| Product colour | Black |
| Illumination | N |
| Number of fans | 1 fan(s) |
| On (off switch) | Y |
| Cooling type | Active |
| Fan diameter | 120 mm |
| Fan speed | 0 - 2100 RPM |
| Performance | |
| Silent mode | Y |
| Noise level | 30.7 dB |
| Certification | CE, CB, TÜV, RCM, CU |
| Purpose | PC |
| Bearing technology | Sleeve |
| Country of origin | Germany |
| Power supply unit (PSU) form factor | ATX |
| Mean time between failures (MTBF) | 100000 h |
| ATX version | 2.4 |
| EPS version | 2.92 |
| 80 PLUS certification | 80 PLUS Bronze |
| Power | |
| Total power | 600 W |
| Power Good signal delay range | 100 - 150 ms |
| Input current | 6 A |
| Efficiency | 89 % |
| Hold time | 17 ms |
| Power protection features | Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage |
| Power factor | 0.95 |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 120 W |
| Combined power (+12V) | 576 W |
| Combined power (+5V) | 120 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+3.3V) | 24 A |
| Max output current (+12V) | 54.17 A |
| Max output current (+5V) | 15 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 3 A |
| AC input frequency | 50 Hz |
| AC input voltage | 200 - 240 V |
| Max output current (+12V2) | 22 A |
| Max output current (+12V1) | 28 A |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 0 - 95 % |
| Operating relative humidity (H-H) | 0 - 90 % |
| Storage temperature (T-T) | -20 - 70 °C |
| Packaging data | |
| Cables included | AC |
| Package depth | 268 mm |
| Package height | 97 mm |
| Package width | 195 mm |
| Manual | Y |
| Manual languages | German, English, Spanish, French, Polish, Russian |
| Package weight | 2300 g |
